Description:

ZTO Walk-Behind Mower

Features:

• Ideal for Intermediate Use: Perfectly suited for various medium-sized jobs.
• Durable & Comfortable: Designed for durability and user comfort.
• Integrated Transmissions: Equipped with reliable mid-sized engines and advanced transmissions for optimal performance.

Specifications:

• Operator Controls: Over the lap controls
• Hour Meter: Digital
• Engine Model: FX730E
• Engine HP: 23.5 hp
• Engine Start Type: Electric
• Max Acres Per Hour: 5.2 Acre/hr
• Fuel Capacity: 13.5 gal
• Forward Speed: 10.5 mph
• Reverse Speed: 4 mph
• Drive System Type: Hydro
• Drive System Transaxle: Hydro-Gear ZT3400

Deck Details:

• Blade Length: 16.5 in
• Blade Quantity: 3
• Deck Configuration: Aero Core
• Deck Discharge: Side Discharge
• Deck Lift System: Foot Pedal Operated
• Deck Size: 48 in
• Deck Steel Gauge: 7 Gauge
• Deck Spindle: Ductile Iron
• Deck Style: Floating
• Deck Type: Floating-side discharge
• Deck Cut Height Max: 5.5 in
• Deck Cut Height Min: 1.5 in

Dimensions & Weight:

• Length: 78.00 in
• Width (Deflector Down): 61.00 in
• Width (Deflector Up): 49.00 in
• Weight: 1080 lb

Tire Details:

• Caster Tire Type: Flat Free
• Caster Tire Diameter: 13.00 in
• Caster Tire Width: 5.00 in
• Caster Wheel Rim Diameter: 6.00 in
• Rear Tire Ply: 4 ply
• Rear Rim Diameter: 12.00 in
• Rear Tire Diameter: 23.00 in
• Rear Tire Width: 10.50 in
